1. High-Precision PCB Assembly and Solder Joint Inspection
Utilizing the 100.0 mm focal length to maintain a safe standoff distance from automated soldering and placement equipment, this application pairs the CA-Series lens with a large-format sensor to capture ultra-high-resolution images of dense printed circuit boards.
Problem SolvedSolves the problem of detecting micro-defects like solder bridges or missing microscopic SMD components on large PCBs without interfering with robotic assembly arms. The 3.45 µm minimal pixel pitch and 30.00 MP resolution reliably resolve sub-millimeter details over a wide area.
100.0 mm focal length30.00 MP resolution3.45 µm minimal pixel pitch1.7" optical class
2. Flat Panel Display (FPD) Pixel-Level Defect Detection
Employed in OLED and micro-LED manufacturing lines, this lens captures highly detailed surface images of flat display panels. The TFL-mount ensures rigid, vibration-free integration into moving metrology gantries over the glass substrate.
Problem SolvedAddresses the challenge of rapidly identifying dead pixels and sub-pixel color anomalies across large displays. The massive 1.7" maximal image circle combined with 30.00 MP resolution enables the system to scan vast screen areas in a single frame without losing the optical clarity required to inspect individual pixels.
Maximal image circle 1.7"TFL-mount (M35 x 0.75)30.00 MP ResolutionMinimal pixel pitch 3.45 µm
3. Automotive EV Battery Cell Dimensional Metrology
Integrated into automated robotic inspection cells to perform non-contact dimensional measurements, weld inspections, and surface crack detection on electric vehicle battery casings and deep machined components.
Problem SolvedOvercomes the difficulty of measuring tight mechanical tolerances on large, complex parts from a distance. The narrow 12.7° x 9.6° angle of view and 0.50 m minimal object distance provide highly accurate, low-distortion telephoto imaging, while the adjustable f/2.8-22 aperture allows engineers to maximize depth of field for inspecting deep cavities.
Angle of view (HxVxD) 12.7° x 9.6° x 15.9°Aperture range (F) 2.8-22Minimal object distance (M.O.D.) 0.50 m100.0 mm focal length
