Basler acA2000-50gc GigE Color Camera

Technical Overview

Compact 2.2 MP GigE color camera with global shutter CMOS sensor, 50 fps, and PoE, offering high-speed imaging for industrial applications.

Key Features

2.2 MP resolution (2046 x 1086 pixels) for detailed imaging.
Fast frame rate of 50 fps for high-speed applications.
CMOSIS CMV2000 progressive scan CMOS sensor with global shutter for distortion-free images of moving objects.
Gigabit Ethernet (GigE) interface for reliable, long-distance data transmission.
Compact form factor (42 x 29 x 29 mm) for easy integration into space-constrained systems.
Supports C-Mount and CS-Mount lenses for flexible optics selection.
Includes digital I/Os for trigger control and synchronization with external devices.
IP30 rated housing provides protection against solid objects larger than 2.5 mm.
Operating temperature range of 0 °C to +50 °C for industrial environments.
Features auto functions for exposure time, gain, and white balance to simplify setup.

Technical Specification Matrix

Parameter	Value
Resolution (H x V)	2046 x 1086 pixels
Resolution (Megapixels)	2.2 MP
Frame Rate	50 fps
Sensor Type	CMOSIS CMV2000 Progressive Scan CMOS, Global Shutter
Sensor Format	2/3"
Pixel Size (H x V)	5.5 x 5.5 µm
Sensing Area (H x V)	11.26 x 5.98 mm
Pixel Depth	12 bits
Interface	GigE (Gigabit Ethernet)
Power Supply	PoE (IEEE 802.3af) or 12 VDC
Power Consumption (PoE)	≈3.0 W
Power Consumption (12 VDC)	≈2.5 W
Operating Temperature	0 to +50 °C
Lens Mount	C-Mount, CS-Mount
Digital I/O Lines	1 input, 1 output
IP Rating	IP30
Conformity	CE (incl. RoHS), EAC, UKCA, UL Listed, FCC, GenICam, GigE Vision, IEEE 802.3af (PoE), REACH, KC
Physical Weight (kg)	0.09
Dimensions L x W x H (cm)	4.2 x 2.9 x 2.9

Industrial Applications

1. High-Speed Quality Control on Production Lines

This camera is perfectly suited for inspecting fast-moving products on automated assembly lines, such as checking for defects in electronics components or verifying packaging integrity. Its 50 fps global shutter ensures crisp, blur-free images of objects in motion.

Problem Solved

Ensures accurate and rapid detection of product flaws, minimizing manufacturing errors and improving throughput.

Global Shutter50 fps2.2 MPGigE VisionHigh-Speed Inspection

2. Robotics and Automation Guidance

The compact form factor and precise global shutter imaging capabilities make this camera ideal for mounting on robotic arms in 'pick and place' applications or for guiding autonomous mobile robots. The GigE interface with PoE simplifies integration and reduces cabling complexity in dynamic environments.

Problem Solved

Provides robots with reliable, high-resolution vision for accurate object manipulation and navigation, even with continuous movement.

Compact SizePoEGlobal ShutterRobotics VisionObject Recognition

3. Medical Device Component Inspection

For critical inspection tasks in medical device manufacturing, this camera offers the resolution and speed needed to examine small, intricate components for microscopic defects. Its IP30 rating provides basic protection, and the reliable GigE interface ensures data integrity in controlled environments.

Problem Solved

Enables meticulous inspection of small medical parts, ensuring compliance with strict quality standards and preventing faulty devices from reaching the market.

2.2 MP ResolutionCMOS SensorGigE InterfacePrecision InspectionQuality Assurance
