1. Semiconductor Wafer Tray Clamping Mechanism
Utilizes the ultra-compact cylinder to securely lock delicate semiconductor wafer carriers into position during automated optical inspection. The cylinder's compact footprint fits into dense machine architectures, while its cleanroom suitability ensures zero particle contamination during actuation.
Problem SolvedSecuring workpieces in tightly constrained, highly sensitive cleanroom environments where traditional bulky clamps would cause spatial interference and particle contamination.
Cleanroom Class 5ISO 14644-15 mm stroke483 N advance forcePosition detection
2. Lithium-Ion Battery Contact Testing Actuator
Deploys the cylinder to press diagnostic test probes against battery cell terminals. The 5 mm short stroke and double-acting functionality provide rapid, repeatable engagement, while elastic cushioning absorbs kinetic energy to prevent impact damage to the delicate test probes.
Problem SolvedApplying consistent, high-force mechanical contact for electrical testing in dense automated battery testing racks without damaging the cells, while maintaining fast cycle times.
Double-actingElastic cushioning0.6 to 10 bar pressure0.4 J impact energy32 mm piston diameter
3. High-Speed Micro-Component Ejection System
Acts as a rapid-response ejector for defective micro-components on an automated electronics assembly line. Its ultra-low moving mass and extremely short stroke enable ultra-fast extension and retraction cycle times within highly confined spaces.
Problem SolvedRemoving defective miniature parts in high-speed, space-constrained manufacturing lines where standard pneumatic cylinders are too bulky and possess too much inertia to respond quickly enough.
37 g moving massM5 pneumatic connectionAnodised aluminium housingProximity switch detection415 N return force
