1. Cleanroom Semiconductor Wafer Clamping System
Utilizes the Festo compact cylinder to delicately hold and position semiconductor wafers during precision inspection and lithography processes within confined automated handlers.
Problem SolvedStandard pneumatic actuators generate particulate contamination and are too bulky for dense micro-assembly tools. The Class 5 ISO 14644-1 cleanroom suitability and compact ISO 21287 profile resolve strict space and purity constraints while delivering a reliable 188 N of clamping force.
Cleanroom Class 5ISO 21287188 N advance stroke forceCompact footprint
2. High-Speed Packaging Conveyor Reject Mechanism
Deployed on pharmaceutical packaging lines to rapidly push defective pill bottles off the main conveyor belt immediately after failing a machine vision inspection.
Problem SolvedHigh-cycle rejection mechanisms often suffer from severe end-of-stroke mechanical wear and vibration. The integrated elastic cushioning rings at both ends absorb up to 0.2 J of impact energy, preventing machine damage, while the 20 mm stroke ensures quick clearance.
Elastic cushioning rings0.2 J impact energy20 mm strokeDouble-acting
3. Automated End-of-Line PCB Testing Jig
Actuates physical buttons, membrane switches, and connectors on manufactured electronic devices to verify mechanical integrity and electrical continuity during automated end-of-line quality control.
Problem SolvedTesting jigs require precise linear travel, confirmation of actuation, and interchangeable tooling for different products. The M6 female thread allows for quick swapping of custom pusher tips, while the proximity switch compatibility enables closed-loop verification of the 20 mm extension.
Position detection via proximity switchFemale thread M60.6 bar to 10 bar operating pressureAutomated Quality Control
