1. Semiconductor Wafer Cassette Positioning
Utilizing the Festo ADN-16-50 compact cylinder in an automated semiconductor manufacturing line to precisely align and push wafer cassettes into processing stations. The female M4 piston rod thread allows for the attachment of custom non-marring pusher heads, while the double-acting mode ensures a controlled return stroke.
Problem SolvedEliminates particle contamination risks during delicate electronic assembly in restricted spaces, relying on the cylinder's Class 5 cleanroom suitability (ISO 14644-1) and compact ISO 21287 footprint.
Cleanroom Class 5ISO 2128750 mm strokeFemale thread M4
2. High-Speed Pharmaceutical Packaging Ejector
Integrated into a high-speed conveyor sorting system, this pneumatic cylinder acts as a rapid reject pusher for lightweight pharmaceutical boxes that fail vision inspection. The proximity switch integration allows for millisecond-level timing synchronization with the optical quality control system.
Problem SolvedPrevents mechanical shock damage to lightweight, sensitive packages during the ejection process by utilizing its built-in elastic cushioning rings at both ends, safely dissipating the 0.15 J impact energy.
Elastic cushioning ringsPosition detection via proximity switch0.15 J Impact energyDouble-acting
3. Automated Press-Fit Jig for Medical Device Assembly
Employed in a specialized automated assembly jig to press-fit small plastic enclosures for portable medical monitors. The cylinder is mounted using its through-hole accessories in a tight multi-axis workstation, operating consistently at an ambient temperature of 22 °C.
Problem SolvedOvercomes the challenge of cracking fragile plastic medical housings by strictly limiting the maximum application force, delivering a highly predictable theoretical advance force of 121 N at 0.6 MPa (6 bar).
121 N advance stroke force16 mm piston diameter0.6 bar ... 10 bar operating pressureCRC 2 Moderate corrosion stress
