UI-5580FA IDS Camera

Out of stock

GigE, CMOS, 15.0 fps, 2560 x 1920, 4.92 MPix, 1/2″, ON Semiconductor, Global Start Shutter, Rolling Shutter

Product:UI-5580FA-C-HQ (colour)

(Illustrations may differ from the original)

SKU: N/A

IDS industrial camera or machine vision cameras was the most easy integration cameras in the market. Therefore is so easy for IDS cameras become most compatible with market most popular machine vision software such as OpenCV, Labview, Cognex and Halcon vision software. IDS also provide wide range of industrial C-mount cameras such GigE, 5 GigE, 10 GigE, USB 2.0, USB 3.0, and USB 3.1 interfacing models.

For find out more IDS Cameras please follow the link.

Meanwhile, if you need technical support please email us [email protected]

Camera Features

The GigE camera UI-5580FA with protection code IP65/67 is fitted with the 4.92 megapixel CMOS sensor (MT9P006STC – colour version) from ON Semiconductor. About half an inch in size, the sensor delivers a resolution of 2560 x 1920 pixels as well as rolling and global start shutter features. Thanks to the innovative A-Pix™ pixel technology, the sensor is extremely sensitive to light, which makes it an affordable alternative to many CCD sensors currently available on the market. This also makes the camera particularly suitable for applications that require maximum precision in colour rendering and crystal clear image quality. The A-Pix™ pixel technology is based on the gathering of light by a light guide, which directs the gathered incident light from the colour filter to the surface of the photo diode. Structure and process improvements in pixel technology have increased the sensitivity of the sensor in the red and green range in particular by up to 30 % compared to the previous version of the sensor.

IDS Software Suite is an identical software package for all IDS cameras. It supports all sensor features. For Windows and Linux (32 and 64 bit)

Camera Data

Item numberAB02314
NameUI-5580FA
FamilyFA
InterfaceGigE
Sensor typeCMOS
ManufacturerON Semiconductor
Frame rate15.0 fps
Resolution (h x v)2560 x 1920
Optical Area5.632 mm x 4.224 mm
ShutterGlobal Start Shutter, Rolling Shutter
Optical class1/2″
Resolution4.92 MPix
Pixel size2.20 µm
IP codeIP65/67
Data sheetUI-5580FA-C-HQ

Camera Functions

  • Full HD resolution using AOI mode
  • Binning for greater contrast
  • Subsampling for fast preview images
WeightN/A
DimensionsN/A
