1. Automotive Paint Shop Pneumatic Clamping Sensor Mounting
In automotive manufacturing, pneumatic cylinders with 63-100mm bore sizes are utilized to clamp and position car chassis parts during the automated painting process. The Festo SMB-3-B (Part 36163) acts as the secure mounting bracket for SMEO and SMTO block-style proximity sensors on these cylinders. Because the environment requires strict adherence to coating standards, the bracket's LABS (PWIS) conformity (VDMA24364-B2-L) ensures that no paint-wetting impairment substances, such as silicones, are present to cause paint defects.
Problem SolvedProvides a reliable sensor mounting solution on heavy pneumatic clamps while preventing the release of paint-wetting impairment substances (PWIS) that could ruin automotive paint finishes.
PWIS ConformityVDMA24364-B2-LProximity SensorBore Size 63-100mmAutomotive Painting
2. End-of-Stroke Detection on Heavy-Duty Packaging Actuators
High-throughput packaging machinery relies on large pneumatic cylinders (Size 3, 63-100mm bore) to push and align heavy bulk materials. Many of these robust cylinders feature a DUO profile or lack integrated sensor slots. The SMB-3-B mounting kit provides a rigid mechanical interface to attach block-design proximity switches (like the Festo SMPO or SMTO series), allowing the PLC to monitor precise extension and retraction limits.
Problem SolvedEnables the retrofitting and secure attachment of block-design proximity sensors onto large pneumatic cylinders without built-in T-slots, ensuring accurate stroke detection for heavy loads.
DUO Profile CylinderBlock Design SensorSize 3 MountingEnd-of-Stroke DetectionPLC Feedback
3. Position Feedback for Material Handling Lifts in Coating Facilities
Industrial material handling systems operating near sensitive coating, printing, or varnishing lines require actuators that do not outgas or shed contaminants. The SMB-3-B is used to mount end-position proximity sensors onto the pneumatic lifts handling pallets of materials. Its VDMA24364-B2-L certification guarantees that the mounting component is completely free of substances that impair paint wetting, meeting strict environmental regulations for surface-finishing plants.
Problem SolvedDelivers a robust, Size 3 compatible sensor mounting bracket for pneumatic lifts that eliminates the risk of introducing silicone or other coating-impairing contaminants into sensitive finishing environments.
VDMA24364-B2-LPneumatic LiftsSensor Mounting KitCoating FacilityActuator Position
