Dimensions
| Dimensional drawing |
 |
| Width |
17.5 mm |
| Height |
113 mm |
| Depth |
114.5 mm |
Ambient Conditions
| Degree of protection |
IP20 |
| Ambient temperature (operation) |
-40 °C … 70 °C (>55°C derating, see technical documentation) |
| -40 °F … 158 °F (>131°F derating, see technical documentation) |
| Ambient temperature (storage/transport) |
-40 °C … 85 °C |
| -40 °F … 185 °F |
| Altitude |
2000 m |
| Permissible humidity (operation) |
20 % … 85 % |
| Permissible humidity (storage/transport) |
20 % … 85 % |
| Shock |
16g, 11 ms |
| Vibration (operation) |
in accordance with IEC 60068-2-6: 5g, 10 Hz … 150 Hz |
Output Data
| Output name |
Analog outputs |
| Number of outputs |
4 |
| Voltage output signal |
0 V … 10 V |
| Max. voltage output signal |
~ 10.83 V |
| Current output signal |
0 mA … 20 mA |
| 4 mA … 20 mA |
| Max. current output signal |
~ 21.67 mA |
| Load |
≥ 10 kΩ |
| ≤ 500 Ω |
| Resolution |
16 bit |
| Precision |
≤ 0.02 % (at 25 °C) |
| typ. 0.5 % (Voltage output) |
| Temperature coefficient, typical |
typ. 0.0025 %/K (at -40 °C … +70 °C) |
| Protective circuit |
Transient protection of outputs |
Commercial Data
| Item number |
2901538 |
| Packing unit |
1 pc |
| Minimum order quantity |
1 pc |
| Product Key |
DNC61D |
| Catalog Page |
Page 383 (C-6-2019) |
| GTIN |
4046356609166 |
| Weight per Piece (including packing) |
205.8 g |
| Weight per Piece (excluding packing) |
174.4 g |
| Customs tariff number |
85177900 |
| Country of origin |
DE |
Connection Data
| Tightening torque |
0.5 Nm … 0.6 Nm |
| 5 lbf-in. … 7 lbf-in. |
| Connection method |
Screw connection |
| Stripping length |
7 mm |
| Conductor cross section, rigid min. |
0.2 mm² |
| Conductor cross section, rigid max. |
2.5 mm² |
| Conductor cross section flexible min. |
0.2 mm² |
| Conductor cross section flexible max. |
2.5 mm² |
| Conductor cross section AWG min. |
24 |
| Conductor cross section AWG max. |
14 |
Standards and Regulations
| Standards/specifications |
EN 61000-6-2 |
| Standards/specifications |
EN 61000-6-4 |
| Standards/specifications |
EN 60079-0 |
| Standards/specifications |
EN 60079-15 |
EMC Data
| Noise immunity |
EN 61000-6-2 |
| Electromagnetic compatibility |
Conformance with EMC Directive 2014/30/EU |
| Noise emission |
EN 61000-6-4 |
