1. Precision Object Detection in Harsh Industrial Environments
This sensor can be used for precise detection of metallic parts on conveyor belts or automated assembly lines, especially in areas exposed to water, dust, or cutting oils.
Problem SolvedEnsures reliable detection of small metallic objects (due to 2.5mm sensing distance) in wet, dusty, or oily conditions without sensor failure, thanks to its IP68/IP68G rating and PBT housing. The wide operating temperature (-25 to +70 °C) allows operation in various factory conditions.
Inductive sensingIP68/IP68G2.5mm sensing distancePBT enclosure-25 to +70 °CObject detectionHarsh environment
2. End-of-Travel Sensing for Robotic Grippers or Small Actuators
Ideal for detecting the exact position of robotic gripper jaws or the end-of-stroke for compact pneumatic/hydraulic cylinders, where space is limited and reliable feedback is critical.
Problem SolvedIts micro-size rectangular form factor (7.4x8x23mm) allows it to fit into confined spaces on robotic arms or compact machinery. The 2.5mm sensing distance provides precise endpoint detection, and its high shock (10,000 m/s²) and vibration resistance (Max. 20 G) ensure durability during repetitive motion.
Micro-size7.4x8x23mm2.5mm sensing distanceEnd-of-travelPosition sensingRobotic gripperShock resistanceVibration resistance
3. High-Speed Counting and Presence Detection in Packaging Machinery
Employed in packaging lines to detect the presence or count of metallic caps, cans, or small components moving at high speeds.
Problem SolvedThe 500 Hz response frequency enables accurate detection and counting of fast-moving metallic objects, preventing miscounts or missed detections common with slower sensors. The PNP NO output integrates easily into PLC control systems for quick processing.
High-speed counting500 Hz response frequencyPresence detectionPNP NO outputPackaging machineryMetallic object
