1. Compact Packaging Machinery Control
Utilizing the 16 bi-directional inputs, this module easily interfaces with up to 16 optical or inductive sensors to monitor package positioning. The 8 PNP transistor outputs (0.5A) provide direct control of pneumatic solenoid valves to handle packaging gates, sorting, and labeling functions.
Problem SolvedResolves the issue of limited panel space and unnecessary bulk by packing high-density I/O into a ultra-compact terminal block footprint that doesn't require its own power supply line.
Bi-directional InputsPNP Transistor OutputsSolenoid ControlCompact Footprint
2. Automated Material Sorting Systems
Deploy the expansion module to manage sorting gates or conveyor diverters. The 16 inputs receive rapid state changes from barcode readers and presence-detection sensors, while the 8 transistor outputs switch pneumatic actuators instantly.
Problem SolvedProvides rapid response and precise actuation in fast-moving assembly environments, ensuring high-speed signals are executed reliably even under high mechanical vibration.
Vibration ResistanceHigh-Speed OutputPNP TransistorDIN Rail Mounting
3. Control Cabinet Retrofits and Optimization
Allows standard cabinet designs to scale with up to 24 additional I/O points per module. Using the included 8 cm bendable cable, it integrates side-by-side with FP-X0 controllers, utilizing existing DIN rail structures without complicating the cabinet's power distribution schema.
Problem SolvedEliminates the cost, space, and thermal output generated by adding dedicated power supplies to modular PLC stacks.
Bus-PoweredTerminal Block InterfaceSpace OptimizationModular Integration
