USD 17.25
DPDT 10A industrial relay with AC220/240V coil. Includes LED/Mechanical indicators and built-in CR surge suppression. Rugged, plug-in design for high-reliability machine logic and motor control.
The Omron MY2N-CR-GS-R AC220/240 is a miniature general-purpose industrial plug-in power relay. Part of the upgraded MY-GS-R series, it features a built-in CR circuit for AC coil surge suppression, a mechanical operation indicator for precise visual status confirmation, and an LED indicator. Engineered to resolve facility stoppages, it operates reliably in extreme temperatures (-55°C to 70°C) and withstands high shock and vibration. When paired with Push-In Plus sockets, it dramatically reduces panel wiring time and prevents wire loosening in demanding industrial automation environments.
| Parameter | Value |
|---|---|
| Coil Voltage | 220/240 VAC |
| Contact Configuration | DPDT (2 Pole) |
| Contact Rating (Resistive) | 10 A at 250 VAC / 10 A at 30 VDC |
| Maximum Switching Power | 2,500 VA (AC) / 300 W (DC) |
| Maximum Contact Voltage | 250 VAC, 220 VDC |
| Electrical Endurance | 500,000 operations min. |
| Ambient Operating Temperature | -55°C to 70°C |
| Contact Resistance | 100 mΩ max. |
| Operation / Release Time | 20 ms max. |
| Dielectric Strength | 2,000 VAC at 50/60 Hz for 1 min (Between coil and contacts) |
| Malfunction Shock Resistance | 20G |
| Insulation Resistance | 1,000 MΩ min. |
| Contact Material | Silver |
| Surge Suppression | Built-in CR circuit |
Used in logic and control circuits for refrigerated warehouses and freezing facilities.
Standard relays can fail or become sluggish in freezing temperatures. The -55°C to 70°C operating range ensures robust switching. The 220/240 VAC coil operates directly off mains voltage, and the CR circuit protects upstream controllers from inductive coil spikes.
Interfacing between PLCs and higher-power loads like solenoids or small motors on active packaging lines.
Constant machine vibration loosens traditional screw terminals, leading to downtime. Its 20G shock resistance and compatibility with Push-In Plus sockets prevent loose wiring, reducing maintenance while reliably switching up to 10A loads.
Acts as an interposing relay to control conveyors, diverters, and automated palletizers in factory environments.
Frequent operation cycles require long-lasting components, and troubleshooting multi-relay panels can be time-consuming. The standard mechanical operation indicator allows instant visual state confirmation, and the high electrical endurance guarantees 500,000 operations.
