Ultra-compact diffuse-reflective sensor with 5 to 30 mm sensing range and built-in amplifier. Features a rapid 1 ms response time, NPN Light-ON output, and IP67-rated PBT housing.
The Omron E3T-FD11 2M is an ultra-compact and ultra-thin photoelectric sensor with a built-in amplifier, engineered for precise object detection in highly constrained industrial spaces. Utilizing a diffuse-reflective sensing method, it delivers a reliable 5 to 30 mm detection range without the need for a separate reflector. Housed in a durable, IP67-rated Polybutylene Terephthalate (PBT) casing, it ensures resilience against dust and moisture in harsh environments. Equipped with a 650 nm red LED light source and an NPN Light-ON output, the sensor guarantees rapid 1 ms response times, making it ideal for high-speed automated machinery.
| Parameter | Value |
|---|---|
| Sensing Method | Diffuse-reflective |
| Sensing Distance | 5 to 30 mm |
| Output Type | NPN, Light-ON |
| Power Supply Voltage | 12 to 24 VDC ±10% |
| Current Consumption | 20 mA max. |
| Control Output Load Current | 50 mA max. |
| Response Time | 1 ms max. (operate or reset) |
| Light Source | Red LED (650 nm) |
| Degree of Protection | IP67 |
| Connection Method | Pre-wired, 2 m cable |
| Housing Material | Polybutylene terephthalate (PBT) |
Mounted directly onto the narrow mechanical arms of robotic end-effectors, this sensor is used to verify the presence of semiconductor wafers before movement is initiated.
Standard sensors are too bulky for micro-robotic arms. The ultra-thin flat design and M2 screw mounting allow seamless integration into tight spaces, preventing collision and handling damage.
Integrated within cramped surface-mount technology (SMT) conveyor lines to trigger automated pick-and-place machines the moment a printed circuit board reaches the correct coordinate.
Eliminates timing lags and physical bottlenecks in electronics assembly by providing a rapid 1 ms response time without taking up valuable machine footprint.
Installed along sterile pharmaceutical packaging tracks to detect the passing of small medical vials and ensure precise counting into shipping cartons.
Provides highly accurate sensing of small objects via a focused red LED, while the IP67-rated PBT housing withstands necessary moisture and wiping associated with clean environments.
