1. CNC Machining Workpiece Detection
In heavy-duty CNC milling centers where cutting fluid is highly prevalent, reliably verifying metal part positioning is challenging. The sensor's zinc diecast housing and oil-resistant cord perform excellently in this environment, while the background suppression correctly identifies the part up to 500 mm away without triggering on reflective machine walls or fluid splashes.
Problem SolvedEliminates sensor degradation from cutting fluids and prevents false triggering caused by shiny machine backgrounds or coolants.
Oil-ResistantIP67Background SuppressionZinc Diecast Housing500mm Range
2. Mixed-Color Packaging Conveyor Lines
In secondary packaging systems, boxes passing on a conveyor frequently vary in size, color, and surface reflectivity. The distance-settable infrared beam strictly detects presence within the 500 mm threshold, completely ignoring the conveyor guide rails moving directly behind the target.
Problem SolvedPrevents varying packaging colors and graphical prints from causing missed detection or double-triggering common in standard diffuse sensors.
BGS (Background Suppression)Infrared LED (860 nm)2 ms Response TimeNPN/PNP Output
3. Automated Washdown Material Handling
Used in material handling sections of food or beverage processing lines where machinery requires frequent cleaning. The sensor's robust NEMA 4X/6P and IP67 construction stands up to rigorous environments while its 2ms response time seamlessly synchronizes downstream high-speed sortation.
Problem SolvedSolves the issue of photoelectric sensor failure in high-humidity/washdown cycles while maintaining rapid 2 ms timing for high-speed sortation.
IP67-25°C to +55°C10-30 VDC2 ms max.
