Omron E3NX-FA11 2M is an NPN smart fiber amplifier with 1 output, 10–30 VDC and response modes from 30 μs to 16 ms.
The Omron E3NX-FA11 2M is a pre-wired smart fiber amplifier with NPN output and 1 output. It uses red 4-element led, 625 nm, operates from 10–30 VDC, and supports response modes SHS: 30 μs; HS: 250 μs; standard: 1 ms; GIGA: 16 ms; smart tuning and dynamic power control are available. The amplifier accepts compatible E32 fiber units, sold separately. Current supply status is not established by consulted manufacturer material and is recorded as Unknown.
A NPN smart fiber amplifier for use with a compatible Omron fiber unit.
| Parameter | Value |
|---|---|
| Product type | smart fiber amplifier unit; fiber unit sold separately |
| Model / output | E3NX-FA11 NPN |
| Inputs / outputs | 1 output |
| Light source | Red 4-element LED, 625 nm |
| Power supply | 10–30 VDC; ripple 10% p-p max. |
| Power consumption | Standard mode: 840 mW max. (35 mA max.) at 24 VDC; Eco ON 650 mW max.; Eco LO 750 mW max. |
| Control output | NPN open collector; 30 VDC max.; 100 mA max. (1–3 amplifiers) or 20 mA max. (4–30); residual 1 V max. below 10 mA or 2 V max. at 10–100 mA |
| Response time modes | SHS: 30 μs; HS: 250 μs; standard: 1 ms; GIGA: 16 ms |
| Sensitivity adjustment | Smart Tuning and manual adjustment |
| Key functions | APC, DPC, timer, eco modes and bank switching |
| Ambient temperature | Group-dependent operation from −25 to +55 °C; storage −30 to +70 °C; no icing or condensation |
| Ambient humidity | Operating/storage 35–85% RH; no condensation |
| Connection | Pre-wired cable, 2 m |
| Housing material | Polycarbonate (PC) case and cover; PVC cable |
| Physical Weight (kg) | Approx. 0.115 kg packed / 0.075 kg sensor only |
| Dimensions L x W x H (cm) | See Omron dimension drawing; numeric dimensions not transcribed |
| Supply status | Unknown; current manufacturer supply state not established |
Engineering suggestions require suitability checks for your installation.
A production station may require a fiber-based detection point with response adjusted to line speed.
Select a response mode appropriate to the required stability and timing, pair with a compatible E32 fiber unit, and validate the full detection cycle on the machine.
A line may need to distinguish a workpiece condition at a small or hard-to-access sensing point.
For CA models, register and evaluate the target in contrast or RGB-ratio color mode; for FA models, tune sensitivity against the actual target and background. Verify output wiring before operation.
