USD 19.03
Omron E32-ZD200 2M is an M6 straight reflective fiber head with 2 m cable, IP67 protection, and R25 minimum bend radius.
The Omron E32-ZD200 2M is a straight reflective fiber optic sensor head with an M6 mount, 2 m plastic fiber and polyethylene sheath. Omron lists IP67 protection, a minimum bend radius of 25 mm and an operating range of -40 to +70°C for the E32 fiber family. With an Omron E3X-HD amplifier, the published reflective sensing distance is up to 1,400 mm in standard mode and 400 mm in high-speed mode, with white paper as the reference target; actual range depends on amplifier mode and setup. The checked manufacturer catalog confirms the exact model specifications, but the current sales status is not established.
An M6 straight reflective fiber head with 2 m cable for Omron fiber amplifiers.
| Parameter | Value |
|---|---|
| Product type | Reflective fiber optic sensor head |
| Sensing method | Reflective |
| Head style | Straight; M6 threaded |
| Sensing distance | With E3X-HD amplifier: 1,400 mm in standard mode; 400 mm in high-speed mode; white paper reference target |
| Optical fiber | Plastic core; polyethylene sheath |
| Cable length | 2 m |
| Minimum bend radius | 25 mm |
| Protection rating | IP67 |
| Operating temperature | -40 to +70°C (E32 family) |
| Compatible amplifier | Omron E3X-HD; verify the amplifier model and mode for the required sensing range |
| Physical Weight (kg) | Not stated in the manufacturer product specification. |
| Dimensions L x W x H (cm) | See the Omron E32-ZD200 dimensional drawing; no overall L × W × H value is stated in the checked catalog. |
| Supply status | Unknown; manufacturer specifications are confirmed, but current sales status was not established. |
Engineering suggestions require suitability checks for your installation.
Reflective fiber sensing can place a compact optical head close to a constrained fixture.
Aim the M6 head at the target and configure a compatible amplifier; verify sensing distance for the actual surface and mode.
The straight head and flexible routing can support optical sensing where a conventional sensor body is difficult to fit.
Route the 2 m fiber without exceeding its 25 mm minimum bend radius and confirm environmental fit with the IP67 head rating.
