IDS peak 2.15.0 / uEye+ firmware 3.54

Type of color filter that is applied to the image. It contains all values of PixelColorFilter, as well as additional values specific to polarization cameras.

Values description

•None: No color filter.

•BayerRG: Bayer filter where red is the first color and green is the second color of the first row.

•BayerGB: Bayer filter where green is the first color and blue is the second color of the first row.

•BayerGR: Bayer filter where green is the first color and red is the second color of the first row.

•BayerBG: Bayer filter where blue is the first color and green is the second color of the first row.

•PolarizationArray: Polarization filter in which the polarization directions are arranged as follows:
90° 45°
135° 0°
horizontally and vertically alternating per pixel

Code example

C++

// Determine the current entry of PixelFilter
std::string value = nodeMapRemoteDevice->FindNode<peak::core::nodes::EnumerationNode>("PixelFilter")->CurrentEntry()->SymbolicValue();
// Get a list of all available entries of PixelFilter
auto allEntries = nodeMapRemoteDevice->FindNode<peak::core::nodes::EnumerationNode>("PixelFilter")->Entries();
std::vector<std::shared_ptr<peak::core::nodes::EnumerationEntryNode>> availableEntries;
for(const auto & entry : allEntries)
{
  if ((entry->AccessStatus()!=peak::core::nodes::NodeAccessStatus::NotAvailable)
          && (entry->AccessStatus()!=peak::core::nodes::NodeAccessStatus::NotImplemented))
  {
      availableEntries.emplace_back(entry);
  }
}

C#

// Determine the current entry of PixelFilter
string value = nodeMapRemoteDevice.FindNode<peak.core.nodes.EnumerationNode>("PixelFilter").CurrentEntry().SymbolicValue();
// Get a list of all available entries of PixelFilter
allEntries = nodeMapRemoteDevice.FindNode<peak.core.nodes.EnumerationNode>("PixelFilter").Entries();
List<string> availableEntries = new List<string>();
for(int i = 0; i < allEntries.Count(); ++i)
{
  if ((allEntries[i].AccessStatus() != peak.core.nodes.NodeAccessStatus.NotAvailable)
          && (allEntries[i].AccessStatus() != peak.core.nodes.NodeAccessStatus.NotImplemented))
  {
      availableEntries.Add(allEntries[i].SymbolicValue());
  }
}

Python

# Determine the current entry of PixelFilter (str)
value = nodeMapRemoteDevice.FindNode("PixelFilter").CurrentEntry().SymbolicValue()
# Get a list of all available entries of PixelFilter
allEntries = nodeMapRemoteDevice.FindNode("PixelFilter").Entries()
availableEntries = []
for entry in allEntries:
  if (entry.AccessStatus() != ids_peak.NodeAccessStatus_NotAvailable
          and entry.AccessStatus() != ids_peak.NodeAccessStatus_NotImplemented):
      availableEntries.append(entry.SymbolicValue())
